Specifications:
– Scanning mode: Electronic phased array
– Elements: 192
– Channel: 32
– Display mode: B, B/M, and Color, PW, CW, PDI
– Frequency: Central 2.8MHz, Cardiac Reverse Harmonic
3.6mhz, and the transcranial fundamental 2.2MHz
– Display Angle: 80°
– Display Depth: 90/160/200/240mm
– Image Adjust: Gain, DYN, Focus, Depth, Harmonic, Denoise
– Puncture assist function: the function of in-plane
puncture guide line, out-of-plane puncture guide line,
automatic blood vessel measurement.
– Noise reduction: 0-1-2-3-4
– Gain: 30db-105db
– Dynamic Range: 40/50/60/70/80/90/100/110
– Measure: Length, Area, Angle, Heart
– Image frame rate: 15~20 Frames/Second
– Battery working time: 1.5hours
– Charge: by USB cable charger
– Dimension: 140×40×25mm
– Weight: 120g
– Wifi type: 802.11g/20MHz/5G/450Mbps
– Working system: Apple iOS and Android, Windows
Additional Information:
| System type | Handheld |
| Probe count | 1 probe |
| Clinical use | Cardiac |
| Monitor size | 12 inch |
| Battery backup | 2 hr |
| Doppler modes | Color |
| Connectivity | USB, WiFi |
